Wheel Nut Torque for Toyota Land Cruiser Prado 150 Series (2009–present)
2009–present · Australian Market
The wheel nut torque for the Toyota Land Cruiser Prado 150 Series (2009–present) is 103 Nm (≈ 76 ft·lbs) for alloy wheels and 112 Nm for steel wheels, tightened in a star pattern with a calibrated torque wrench.
Alloy Wheels
≈ 76 ft·lbs
Steel Wheels
≈ 83 ft·lbs
Socket Size
21mm
Bolt Pattern
6x139.7
Thread Size
M12 x 1.5
Source
Toyota AIM 004-425-12 Accessory Installation Manual (Rev. 12) — LC150 2015/06–: 103 Nm alloy / 112 Nm steel. Cross-confirmed by Prado 150 owner community (4x4community.co.za). RM990E covers only the 90/120 series — prior '112 Nm all-wheels' was a misattribution. Corrected 2026-08.
Always verify with your vehicle's owner manual. Use a calibrated torque wrench. TorqSpec accepts no liability for damage or injury.
Frequently Asked Questions
What is the wheel nut torque for the Toyota Land Cruiser Prado 150 Series (2009–present)?
The wheel nut torque for the Toyota Land Cruiser Prado 150 Series is 103 Nm (≈ 76 ft·lbs), shown in the torque specification card at the top of this page. Use a calibrated torque wrench set to this value, following the star-pattern tightening sequence shown in the diagram further down this page.
What socket size do I need for Toyota Land Cruiser Prado wheel nuts?
You'll need a 21mm socket, shown in the Socket Size card in the hardware specifications section of this page. The matching M12 x 1.5 thread and 6x139.7 stud pattern are displayed alongside it in the same grid.
What is the bolt pattern for the Toyota Land Cruiser Prado 150 Series?
The Toyota Land Cruiser Prado 150 Series uses a 6x139.7 bolt pattern (6 studs), shown in the Bolt Pattern card in the hardware specifications section of this page. The thread size is M12 x 1.5.
What is the correct wheel nut tightening sequence for the Toyota Land Cruiser Prado?
Tighten the wheel nuts in a star (cross) pattern — never sequentially around the wheel — so clamping force spreads evenly across the 6 studs. The exact tightening sequence for the 6-stud Toyota Land Cruiser Prado wheel is shown in the diagram on this page. Torque in stages (snug, then half torque, then full torque) and re-check after 50–100 km.
Is the wheel nut torque different for steel and alloy wheels on the Toyota Land Cruiser Prado?
Yes. This vehicle has separate torque specs for alloy and steel wheels. The torque specification card at the top of this page shows both values side by side — 103 Nm (≈ 76 ft·lbs) for alloy wheels and 112 Nm for steel wheels. Check which wheel type you are fitting and use the matching figure.
6-Stud Wheel
Correct Tightening Pattern
Sequence: 1 → 4 → 2 → 5 → 3 → 6
